Camera PTZ Ngoài Trời DaHua ECA7B1231-HNP-XA-F

Camera

Image Sensor

1/1.8″ CMOS

Pixel

2 MP

Max. Resolution

1920 (H) × 1080 (V)

ROM

4 GB

RAM

1 GB

Electronic Shutter Speed

1/1 s–1/30,000 s

Scanning System

Progressive

Min. Illumination

Color: 0.001 lux@F1.6
B/W: 0.0001 lux@F1.6
0 lux (IR light on)

Illumination Distance

100 m (328.08 ft)

Illuminator On/Off Control

Zoom Prio; Manual; Smart IR; Off

Illuminator Number

4 (IR)

Wiper

Wiper

Lens

Focal Length

6 mm–186 mm

Max. Aperture

F1.6–F4.0

Field of View

H: 59.8°–2.8°; V: 33.7°–1.9°; D: 63.3°–4°

Optical Zoom

31×

Focus Control

Auto; semi-auto; manual

Iris Control

Auto; semi-auto; manual

PTZ

Preset

300

Tour

8 (up to 32 presets per tour)

Power-off Memory

Yes

Idle Motion

Preset;Tour

Intelligence

Video Metadata

Motor vehicle, non-motor vehicle, face, and human body detection; tracking; optimization; capturing pictures; uploading high-quality face snapshots

IVS (Perimeter Protection)

Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification

Face Detection

Supports face detection, optimization, face bounding box, capturing pictures, uploading high-quality face snapshots, and face enhancement; Supports attributes extraction. 6 attributes and 8 expressions: Gender, age, glasses, expressions (angry, sad, hate, scary, surprise, calm, happy and confused), mask, mustache; Supports face cutout: Face, one-inch photo. Capturing strategies include

real-time capturing, optimization, and quality first

Job Monitoring

Helmet detection; helmet color recognition

SMD

Yes

Video

Video Compression

H.265;H.264;H.264B;MJPEG;Smart H.264;Smart H.265

Streaming Capability

3 streams

Resolution

1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704×576/704×480); CIF (352×288/352×240)

Video Frame Rate

Main stream: 1080p/1.3M/720p (1–25/30 fps)
Sub stream 1: D1/CIF (1–25/30 fps)
Sub stream 2: 1080p/1.3M/720p (1–25/30 fps)

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 2816 kbps–8192 kbps
H.265: 1024 kbps–7936 kbps

Day/Night

Auto (ICR)/Color/B/W

BLC

Yes

WDR

Yes

HLC

Yes

White Balance

Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp

Gain Control

Auto; manual

Noise Reduction

2D NR; 3D NR

Motion Detection

Yes

Region of Interest (RoI)

Yes

Image Stabilization

Electronic (EIS)

Defog

Electronic

Digital Zoom

16×

Image Rotation

180°

Privacy Masking

Up to 24 areas can be set, with up to 8 areas in the same view. It also supports multiple color blocks and mosaics.

S/N Ratio

≥55 dB

Audio

Audio Compression

G.711a; G.711Mu; G726; MPEG2-Layer2; G722.1; G729; PCM; G723

Network

Network Port

1 (crystal head, 10/100 Base-T)

Network Protocol

HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;IPv6;802.1x;SSL;Qos;FTP;UPnP;

ICMP;SNMP;SNMPv1/v2c/v3(MIB-2);IGMP;ARP;RTCP;RTP;PPPoE;IP Filter;RTMP;Bonjour;TCP;SMB;NFS

Interoperability

ONVIF Profile S&G&T; 35114 A level; CGI

Streaming Method

Unicast/Multicast

User/Host

20 (total bandwidth: 64 M)

Storage

FTP: Micro SD card (256 G); NAS

Browser

IE 7 and later versions
Chrome 42 and earlier versions
Firefox 52 and earlier versions
Safari

Management Software

Smart PSS;DSS;DMSS;Easy4ip;IVSS;NVR;Smart Player

Mobile Client

iOS;Android;iPhone;iPad

Certification

Certifications

FCC: 47 CFR FCC Part15, Subpart B, ClassA
CE: EN55032/EN55024/EN55035/EN50130-4/EN 61000-3-3/EN IEC 61000-3-2/EN 62368-1
IECEx: IEC 60079-0/IEC 60079-1/IEC 60079-31
ATEX: IEC 60079-0/IEC 60079-1/IEC 60079-31

Port

RS-485

1 (baud rate: 1200 bps–9600 bps)

Audio Input

1 channel

Audio Output

1 channel

Alarm Linkage

Capture; preset; tour; pattern; recordings on SD card; alarm digital input; send email

Alarm Event

Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card

state detection; memory space detection

Optical Fiber

100 M single fiber port
Specifications: 1310 nm TX/1550 nm RX
Transmission Distance: 20 km (12.43 mi)

Alarm I/O

2/1

Audio I/O

1/1

Power

Power Supply

100–240 VAC

Power Consumption

Basic: 10 W
Max.: 19 W (IR on)

Environment

Operating Temperature

–40 °C to +60 °C (–40 °F to +140 °F)

Operating Humidity

≤95%

Protection

IP68

Structure

Casing Material

Stainless steel

Product Dimensions

192 mm × 488 mm × 284 mm (7.56″ × 19.21″ × 11.18″)

Net Weight

10 kg (22.05 lb)

Gross Weight

16 kg (35.27 lb)
