Camera PTZ Ngoài Trời DaHua ECA3A1404-HNR-XB-F

Camera

Image Sensor

1/2.8″ CMOS

Pixel

4MP

Max. Resolution

2560 (H) × 1440 (V)

ROM

4 GB

RAM

1 GB

Electronic Shutter Speed

1/1 s–1/30000 s

Scanning System

Progressive

Min. Illumination

Color: 0.005 Lux@F1.8
B/W: 0.0005 Lux@F1.8
0 Lux (IR on)

Illumination Distance

40 m (131.23 ft)

Illuminator On/Off Control

Zoom Prio/Manual/SmartIR/Off

Illuminator Number

3 IR lights

Lens

Focal Length

2.8 mm–12 mm

Max. Aperture

F1.8–F2.7

Field of View

H: 42.8°–91.9°
V: 23.8°–49.4°
D: 49.1°–109.4°

Optical Zoom

4x

Focus Control

Auto/Semi-Auto/Manual

Close Focus Distance

0.2 m–0.5 m (0.66 ft–1.64 ft)

Iris Control

Fixed

DORI Distance

Detect

Observe

Recognize

Identify

240 m (787.40 ft)

95 m (311.68 ft)

48 m (157.48 ft)

24 m

(78.74 ft)

PTZ

Preset

300

Power-off Memory

Support

Idle Motion

Preset

Artificial Intelligence

Smart Capture

Support human, motor vehicle and non-motor vehicle image capture.

Perimeter Protection

Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc.

Face Detection

Support

Video

Compression

H.265; H.264B; H.264M; H.264H; MJPEG; H.265+; H.264+

Streaming Capability

3 streams

Resolution

4M (2560 × 1440); 3M (2048 × 1536); 1080P (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576); CIF (352 × 288)

Frame Rate

Main stream: 4M/3M/1080P/960P/720P (1–25/30 fps)
Sub stream 1: D1/CIF (1–25/30 fps)
Sub stream 2: 1080P/960P/720P (1–25/30 fps)

Bit Rate Control

Variable/Constant

Bit Rate

H.264: 2816 Kbps–8192 Kbps

Day/Night

Auto (ICR)/Color/B/W

BLC

Support

WDR

120 dB

HLC

Support

White Balance

Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural light/Street lamp

Gain Control

Auto/Manual

Noise Reduction

2D/3D

Motion Detection

Support

Region of Interest (RoI)

Support

Image Stabilization

Electronic

Defog

Electronic

Digital Zoom

16x

Flip

180°

Privacy Masking

Up to 24 areas, and up to 8 areas in the same view

S/N Ratio

55 dB

Audio

Compression

G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G722.1; G729; G723

Network

Ethernet

1 (crystal head, 10/100Base-T)

Protocol

IPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMP; DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; SNMP v1/v2c/v3 (MIB-2); RTCP; RTMP

Interoperability

ONVIF (Profile S&G&T); CGI

Streaming Method

Unicast/Multicast

User/Host

20

Storage

FTP; Micro SD card (256G); NAS

Browser

IE7 and later versions
Chrome 42 and earlier versions
Firefox 52 and earlier versions
Safari

Management Software

Smart PSS; DSS; DMSS; IVSS

Mobile Phone

IOS; Android

Certification

Certifications

CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014
ATEX: II 2 G Ex db IIC T6 Gb, II 2 D Ex tb IIIC T80°C Db
IECEx: Ex db IIC T6 Gb, Ex tb IIIC T80°C Db

Port

Audio Input

1

Audio Output

1

Two-way Audio

Support

Alarm Linkage

Capture; preset; record; alarm digital output; audio; send email

Alarm Event

Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection; abnormal power supply detection

Optical Fiber

100M single fiber
Transmission specification: 1310nm TX/1550nm RX
Distance: 20 km (65616.80 ft)

Power

Power Supply

DC12V/1.5A±10%

Power Consumption

Basic: 4W
Max.: 9W (IR light on)

Environment

Operating Temperature

–40°C to +60°C (–40°F to +140°F)

Operating Humidity

≤ 95%

Protection

IP68; TVS 6000V lightning proof; surge protection; voltage transient protection

Structure

Casing

SUS304/SUS316L (customizable)

Dimensions

215 mm x 149 mm x 151 mm (8.46″ × 5.87″ × 5.94″)

(L × W × H)

Net Weight

3 kg (6.61 lb)

Gross Weight

6.3 kg (13.89 lb)
